Enhance safety and visibility of driving activities

Know what’s happening in the vehicle in real-time to improve driving safety, equipped the AI technology to detect driver’s distraction.

Drive safely, avoid distraction

Reduce the risk of accidents by monitoring and addressing driver distractions.

Automatically record journeys

Journey documentation system provides certainty in the event of an accident. Protection can be done with tangible evidence.

Suitable for Industries

Manufacturing, Distribution/Logistics, Energy, and Waste.

Network

WiFi

2.4GHz, 802.11 b/g/n

BT

BLE 4.0

Eurasian Version

FDD LTE: B1/B3/B5/B7/B8/B19/B20
TDD LTE: B38/B39/B40/B41 (100M)
WCDMA: B1/B2/B5/B8
GSM: 850/900/1800/1900MHz

American Version

FDD LTE: B2/B3/B4/B5/B7/B12/B17
TDD LTE: B38/B41 (100M)
WCDMA: B2/B4/B5
GSM: 850/1800/1900MHz

Configuration

CPU

Quad-core 1.4GHz A53

Operating System

Android 8.1 GO

GNSS

GPS+BDS

Sensor

6-axis

Mic & Speaker

Yes

Data Interface

Micro USB 2.0

Memory

TF card (Max. 256GB)

SIM Card

Nano

LED

Red (Power), Blue (Cellular), Green (GNSS)

Supply Voltage

DC9-30V (Suitable for cars, trucks, buses, electric automobiles, etc.)

Camera

Main Unit

Front camera: 1920×1080/25FPS/F2.2/full color

Subcamera (Optional)

1. Remote cabin-view camera: 1280×720/15FPS/F2.0/full color in daytime & monochrome in dim light
2. IP67 blindspot camera: 1280×720/full color around the clock

Video Coding

H.264

Others

Battery

External: 450mAh

Power Supply

Power cable: B+/ACC/GND

Operating Temperature

–20°C to +65°C

Operating Voltage

9-30V DC

Device Weight

233g

Device Dimension

109x69x52mm

Certifications

FCC/CE/RoHS
